DESCRIPTION

Basic Info

Model NO.	DD703
Precision	Normal Precision
Certification	CE, ISO 9001
Condition	New
Worktable Travel(X *Y)	200*300 mm
Main Spindle Speed	60 Rpm
Water Tank	25L
Power Supply	3n-380V/50Hz
Transport Package	to Be Packed in Wooden Cases, Suitble for Export
Specification	1060*750*1700 mm; weight 536kg
Trademark	TOPSCNC
Origin	Taizhou, Jiangsu, China
HS Code	8456301090
Production Capacity	100set/Month

Product Description

Technique parameters

Technique parameters	unit	DD703	DD703.30	DD703.32	DD703.40
Worktable size	mm	320x440	320x440	360x610	460x690
Worktable travel	mm	200×300	300×400	320×400	400x500
Z-axis travel	mm	280	300	300	300
Max.load on table	mm	200	200	200	200
Main spindle speed	rpm	60
Diameter of electrode	mm	φ0.3-φ3
MAX.distance from guider to worktable	mm	240	300	400	500
water tank	L	25
Filtering model		Shallow-gap filter
Working medium		water
MAX.working pressure	Mpa	7
Power supply		380V,3Ph,50Hz
Max.woking current	A	30
Power consumption	Kw	3
Machine weight	kg	700	850	1300	1700
Machine demensions	mm	1060×750×1700	1060×750×1760	1550×1170×1800	1800x1380x1800

Products advantages1) It can drill small holes on the materials. Such as stainless steel, quenched steel, carbide,copper, aluminium,etc2) It can drill the deep holes with diameters 0.3-3mm and depth-diameter ratio 200:1 or more. 3)Working speed is 30-60mm depth per minute it can directly drill on oblique curved surfaces. 4) It can water as workingfluid.5) It can become a machine with multi-axis numerical control or numerical display for the user requirement.

Our FactoryOur Services

1) Quality : We take care of the product quality in order to provide good service to our customers.2)Warranty: One year after shipment,consumables are not included.3)The quotation do not include installation and education training fee.4) Payment Method: T/T or L/C5) Delivery time : 20--25 days 6) Packing : Standard export wooden cases 7)Port: Shanghai
